XML-RPC 之 Apache XML-RPC 实例
作者：王恩建 来源：http://www.sentom.net
XML-RPC 是工作在 Internet 上的远程过程调用协议。通俗点讲，就是使用 HTTP 协议交互，交互的载体是 XML 文件。XML-RPC 具体的规范说 明请参考这里。
图片来自XML-RPC官方网站
XML-RPC 规范定义了六种数据类型，下表是这六种数据类型与 Java 的数据类型对应表。
XML-RPC Java
<i4> 或 <int> int
<boolean> boolean
<string> java.lang.String
<double> double
<dateTime.iso8601> java.util.Date
<struct> java.util.Hashtable
<array> java.util.Vector
<base64> byte[ ]
XML-RPC 规范的各种平台都有具体实现，XML-RPC 规范的 Java 实现都有好几种，这里我们选择了 Apache XML-RPC。
XML-RPC 服务端实现
先定义一个简单业务对象 MyHandler，远程客户端将调用该对象的方法，具体代码如下：
package net.sentom.xmlrpc;
public class MyHandler {
public String sayHello(String str){
return "Hello," + str;
}
}
然后定义一个 Servlet 名叫 MyXmlRpcServer，远程客户端通过 HTTP-POST 访问该 Servlet。
package net.sentom.xmlrpc;
import java.io.IOException;
import java.io.OutputStream;
import javax.servlet.ServletException;
import javax.servlet.http.HttpServlet;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import org.apache.xmlrpc.XmlRpcServer;
public class MyXmlRpcServer extends HttpServlet {
public void doPost(HttpServletRequest request, HttpServletResponse response)
throws ServletException, IOException {
XmlRpcServer xmlrpc = new XmlRpcServer();
xmlrpc.addHandler("myHandler", new MyHandler());
byte[] result = xmlrpc.execute(request.getInputStream());
response.setContentType("text/xml");
response.setContentLength(result.length);
OutputStream out = response.getOutputStream();
out.write(result);
out.flush();
}
}
需要特别说明是：
xmlrpc.addHandler("myHandler", new MyHandler());
为了便于理解，这里可以看成普通的：
MyHandler myHandler = new MyHandler();
最后在web.xml文件中加入以下几行：
<servlet>
<servlet-name>MyXmlRpcServer</servlet-name>
<servlet-class>net.sentom.xmlrpc.MyXmlRpcServer</servlet-class>
</servlet>
<servlet-mapping>
<servlet-name>MyXmlRpcServer</servlet-name>
<url-pattern>/MyXmlRpcServer</url-pattern>
</servlet-mapping>
XML-RPC 客户端实现
客户端相对简单一些，先来一个 Java 客户端实现 MyXmlRpcClient:
package net.sentom.xmlrpc;
import java.io.IOException;
import java.net.MalformedURLException;
import java.util.Vector;
import org.apache.xmlrpc.XmlRpcClient;
import org.apache.xmlrpc.XmlRpcException;
public class MyXmlRpcClient {
public static void main(String[] args) {
try {
XmlRpcClient xmlrpc = new XmlRpcClient("http://localhost:8080/XMLRPC/MyXmlRpcServer");
Vector params = new Vector();
params.addElement("Tom");
String result = (String) xmlrpc.execute("myHandler.sayHello",params);
System.out.println(result);
} catch (MalformedURLException e) {
System.out.println(e.toString());
} catch (XmlRpcException e) {
System.out.println(e.toString());
} catch (IOException e) {
e.printStackTrace();
}
}
http://localhost:8080/XMLRPC/MyXmlRpcServer 为 MyXmlRpcServer 的访问URL。
String result = (String) xmlrpc.execute("myHandler.sayHello",params);
再来一个 Python 客户端实现
import xmlrpclib
url = 'http://localhost:8080/XMLRPC/MyXmlRpcServer';
server = xmlrpclib.Server(url);
print server.myHandler.sayHello('Tom');
添加评论
9:12 | 固定链接 | 引用通告 (0) | 记录它 | Open Source
固定链接 关闭
http://spaces.msn.com/lzhuacuo/blog/cns!18730E989D068035!507.entry
XML-RPC规范(中文版) （转自：http://spaces.msn.com/lzhuacuo/blog/cns!18730E989D068035!504.entry?_c11_blogpart_blogpart=blogview&_c=blogpart#permalink）
XML-RPC规范(中文版)
把这篇文章转到blog里，希望rainbowsoft能看见有朝一日给blog写支持客户端post的功能时能用上
Tue, Jun 15, 1999; by Dave Winer. （翻译:滴水 最后修改时间:2005-3-15 后续完善）
更新 6/30/03 DW
更新 10/16/99 DW
更新 1/21/99 DW
本规范说明的XML-RPC协议实现UserLand Frontier 5.1。
关于非技术性说明，请访问XML-RPC for Newbies。
文档提供了实现XML-RPC所需要的所有信息。
前言
XML-RPC是一种基于Internet的远程函数调用协议。
XML-RPC消息都是HTTP-POST请求。请求的主要部分的XML。服务器端执行后的返回结果同样也是XML格式。
函数调用的参数可以是scalars, numbers, strings, dates等等；也可以是混合型的记录和结构体。
Request请求样式
下面是一个XML-RPC请求的例子：
POST /RPC2 HTTP/1.0
User-Agent: Frontier/5.1.2 (WinNT)
Host: betty.userland.com
Content-Type: text/xml
Content-length: 181
<?xml version="1.0"?>
<methodCall>
<methodName>examples.getStateName</methodName>
<params>
<param>
<value><i4>41</i4></value>
</param>
</params>
</methodCall>
关于请求头
第一行的URI格式不是特定的。可以为空，如果服务器只处理XML-RPC请求甚至可以只是简单的一个斜线。可是，如果服务器除了XML-RPC外还提供其他的HTTP请求，URI可以帮助我们把请求指向特定的XML-RPC服务。
User-Agent和Host项是必须的。
Content-Type的值必须是text/xml.
Content-Length必须指定，而且必须是正确的值。
有效的格式
XML-RPC具有和XML一样的有效格式，并且是一个<methodCall>结构。
<methodCall>必须包含一个值为字符型的<methodName>子元素，用来表明被调用的方法。这个字符必须符合以下规定：大小写字母、数字0-9、下划线、点、冒号和斜线。至于怎么解释这个字符串将有服务器端来决定。
例如，methodName可以是一个包含执行request请求的文件的名字，可以是数据表中列的名字，还可以是表示目录和文件结构的路径。
如果远程调用接受参数，<methodCall>就必须包含<params>子元素。<params>可以包含任意个<param>元素，每个<param>包含一个<value>子元素。
Scalar <value>s <value>
<value>值被嵌入类型标签中，支持的类型如下表:
Tag Type Example
<i4> or <int> four-byte signed integer -12
<boolean> 0 (false) or 1 (true) 1
<string> string hello world
<double> double-precision signed floating point number -12.214
<dateTime.iso8601> date/time 19980717T14:08:55
<base64> base64-encoded binary eW91IGNhbid0IHJlYWQgdGhpcyE=
如果没有指定类型，默认为字符串。
<struct>s
参数值可以是<struct>。
每个<struct>包含若干<member>，每个<member>包含一个<name>和一个<value>.
如果所示为包含两个值的<struct>
<struct>
<member>
<name>lowerBound</name>
<value><i4>18</i4></value>
</member>
<member>
<name>upperBound</name>
<value><i4>139</i4></value>
</member>
</struct>
<struct>是可以递归使用的，任何<value>都里还可以<struct>或其他任何类型，包括后面将要说明的<array>。
<array>s
值可以个<array>
一个<array>简单的有一个<data>元素。<data>可以是任何合法类型。
下面是一个有4个值的array：
<array>
<data>
<value><i4>12</i4></value>
<value><string>Egypt</string></value>
<value><boolean>0</boolean></value>
<value><i4>-31</i4></value>
</data>
</array>
<array> elements do not have names.
<array> 元素没有名字。
你可以混合使用上面列出的几种类型。
<arrays>可以递归使用，其值可以是<array>或其他类型，包括上面说明的<strut>。
Response应答样式
下面是一个 XML-RPC请求：
HTTP/1.1 200 OK
Connection: close
Content-Length: 158
Content-Type: text/xml
Date: Fri, 17 Jul 1998 19:55:08 GMT
Server: UserLand Frontier/5.1.2-WinNT
<?xml version="1.0"?>
<methodResponse>
<params>
<param>
<value><string>South Dakota</string></value>
</param>
</params>
</methodResponse>
Respnse应答格式
除非底层操作出现错，否则总是返回200 OK.
Content-Type是text/xml。必须设置Content-Length，并且必须是正确的值。
应到内容是一个简单的XML，可是是<methodResponse>包含一个<params>,<params>包含一个<param>,<param>包含一个<value>。
<methodResponse>可能含有一个<fault>标签。<fault>的值为<struct>类型,<struct>有两个元素，值为<int>的<faultCode>和值为<string>的<faultString>。
<methodResponse>不能既有<fault>又有<params>。
Fault example
HTTP/1.1 200 OK
Connection: close
Content-Length: 426
Content-Type: text/xml
Date: Fri, 17 Jul 1998 19:55:02 GMT
Server: UserLand Frontier/5.1.2-WinNT
<?xml version="1.0"?>
<methodResponse>
<fault>
<value>
<struct>
<member>
<name>faultCode</name>
<value><int>4</int></value>
</member>
<member>
<name>faultString</name>
<value><string>Too many parameters.</string></value>
</member>
</struct>
</value>
</fault>
</methodResponse>
Strategies/Goals
Firewalls. The goal of this protocol is to lay a compatible foundation across different environments, no new power is provided beyond the capabilities of the CGI interface. Firewall software can watch for POSTs whose Content-Type is text/xml.
Discoverability. We wanted a clean, extensible format that's very simple. It should be possible for an HTML coder to be able to look at a file containing an XML-RPC procedure call, understand what it's doing, and be able to modify it and have it work on the first or second try.
Easy to implement. We also wanted it to be an easy to implement protocol that could quickly be adapted to run in other environments or on other operating systems.
Updated 1/21/99 DW
The following questions came up on the UserLand discussion group as XML-RPC was being implemented in Python.
The Response Format section says "The body of the response is a single XML structure, a <methodResponse>, which can contain a single <params>..." This is confusing. Can we leave out the <params>?
No you cannot leave it out if the procedure executed successfully. There are only two options, either a response contains a <params> structure or it contains a <fault> structure. That's why we used the word "can" in that sentence.
Is "boolean" a distinct data type, or can boolean values be interchanged with integers (e.g. zero=false, non-zero=true)?
Yes, boolean is a distinct data type. Some languages/environments allow for an easy coercion from zero to false and one to true, but if you mean true, send a boolean type with the value true, so your intent can't possibly be misunderstood.
What is the legal syntax (and range) for integers? How to deal with leading zeros? Is a leading plus sign allowed? How to deal with whitespace?
An integer is a 32-bit signed number. You can include a plus or minus at the beginning of a string of numeric characters. Leading zeros are collapsed. Whitespace is not permitted. Just numeric characters preceeded by a plus or minus.
What is the legal syntax (and range) for floating point values (doubles)? How is the exponent represented? How to deal with whitespace? Can infinity and "not a number" be represented?
There is no representation for infinity or negative infinity or "not a number". At this time, only decimal point notation is allowed, a plus or a minus, followed by any number of numeric characters, followed by a period and any number of numeric characters. Whitespace is not allowed. The range of allowable values is implementation-dependent, is not specified.
What characters are allowed in strings? Non-printable characters? Null characters? Can a "string" be used to hold an arbitrary chunk of binary data?
Any characters are allowed in a string except < and &, which are encoded as < and &. A string can be used to encode binary data.
Does the "struct" element keep the order of keys. Or in other words, is the struct "foo=1, bar=2" equivalent to "bar=2, foo=1" or not?
The struct element does not preserve the order of the keys. The two structs are equivalent.
Can the <fault> struct contain other members than <faultCode> and <faultString>? Is there a global list of faultCodes? (so they can be mapped to distinct exceptions for languages like Python and Java)?
A <fault> struct may not contain members other than those specified. This is true for all other structures. We believe the specification is flexible enough so that all reasonable data-transfer needs can be accomodated within the specified structures. If you believe strongly that this is not true, please post a message on the discussion group.
There is no global list of fault codes. It is up to the server implementer, or higher-level standards to specify fault codes.
What timezone should be assumed for the dateTime.iso8601 type? UTC? localtime?
Don't assume a timezone. It should be specified by the server in its documentation what assumptions it makes about timezones.
Additions
<base64> type. 1/21/99 DW.
Updated 6/30/03 DW
Removed "ASCII" from definition of string.
Changed copyright dates, below, to 1999-2003 from 1998-99.
Copyright and disclaimer
? Copyright 1998-2003 UserLand Software. All Rights Reserved.
This document and translations of it may be copied and furnished to others, and derivative works that comment on or otherwise explain it or assist in its implementation may be prepared, copied, published and distributed, in whole or in part, without restriction of any kind, provided that the above copyright notice and these paragraphs are included on all such copies and derivative works.
This document may not be modified in any way, such as by removing the copyright notice or references to UserLand or other organizations. Further, while these copyright restrictions apply to the written XML-RPC specification, no claim of ownership is made by UserLand to the protocol it describes. Any party may, for commercial or non-commercial purposes, implement this protocol without royalty or license fee to UserLand. The limited permissions granted herein are perpetual and will not be revoked by UserLand or its successors or assigns.
This document and the information contained herein is provided on an "AS IS" basis and USERLAND DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WARRANTY THAT THE USE OF THE INFORMATION HEREIN WILL NOT INFRINGE ANY RIGHTS OR ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
