我的AMD K6-2 450 , PCI S3 2M display card, OK-520 双飞燕2D 串口鼠标 老机还花了一些时间来配置显卡和鼠标,记在这里参考。
这里在系统默认的配置文件上有两点改动:
1、显卡的
默认是
Section "Device"
Identifier "Generic Video Card"
Driver "s3"
BusID "PCI:0:8:0"
EndSection
|
|
不能进入图形界面,把Driver改成 vesa解决。“ VideoRam 2048”好像不是必须的。
2、鼠标
原来的OK-520 双飞燕2D 串口鼠标在图形界面下不能用,添加如下内容解决(转自:http://atoz.org.cn/blog/?cat=8)
在Ubuntu 5.10中配置使用串口鼠标
Filed under: Ubuntu 5.10 (Breezy), Linux, System Admin — jjheng @ 10:30 am
1、在Ubuntu中使用串口鼠标需要手工对xorg.conf文件进行配置
$ sudo vi /etc/X11/xorg.conf
2、在xorg.conf文件中搜索“Section “InputDevice” ”,并在其下添加如下内容:
Section "InputDevice"
Identifier "Serial Mouse"
Driver "mouse"
Option "Protocol" "Microsoft"
Option "Device" "/dev/ttyS0"
Option "SendCoreEvents" "true"
EndSection
3、在xorg.conf文件中搜索“Section “ServerLayout””,并在其中加入如下行:
InputDevice "Serial Mouse" "CorePointer"
修改之后的“Section “ServerLayout””内容如下所示:
Section "ServerLayout"
Identifier "Default Layout"
Screen "Default Screen"
InputDevice "Generic Keyboard"
InputDevice "Configured Mouse"
InputDevice "Synaptics Touchpad"
InputDevice "Serial Mouse" "CorePointer"
EndSection
4、使用“Ctrl+Alt+Backspace”组合键重新启动X-Window后就可以正常使用串口鼠标了。
|
|
配置文件正文
****************************************************************************************************************
# /etc/X11/xorg.conf (xorg X Window System server configuration file)
#
# This file was generated by dexconf, the Debian X Configuration tool, using
# values from the debconf database.
#
# Edit this file with caution, and see the /etc/X11/xorg.conf manual page.
# (Type "man /etc/X11/xorg.conf" at the shell prompt.)
#
# This file is automatically updated on xserver-xorg package upgrades *only*
# if it has not been modified since the last upgrade of the xserver-xorg
# package.
#
# If you have edited this file but would like it to be automatically updated
# again, run the following command:
# sudo dpkg-reconfigure -phigh xserver-xorg
Section "Files"
FontPath "/usr/share/X11/fonts/misc"
FontPath "/usr/share/X11/fonts/cyrillic"
FontPath "/usr/share/X11/fonts/100dpi/:unscaled"
FontPath "/usr/share/X11/fonts/75dpi/:unscaled"
FontPath "/usr/share/X11/fonts/Type1"
FontPath "/usr/share/X11/fonts/100dpi"
FontPath "/usr/share/X11/fonts/75dpi"
# path to defoma fonts
FontPath "/var/lib/defoma/x-ttcidfont-conf.d/dirs/TrueType"
EndSection
Section "Module"
Load "i2c"
Load "bitmap"
Load "ddc"
Load "dri"
Load "extmod"
Load "freetype"
Load "glx"
Load "int10"
Load "type1"
Load "vbe"
EndSection
Section "InputDevice"
Identifier "Generic Keyboard"
Driver "kbd"
Option "CoreKeyboard"
Option "XkbRules" "xorg"
Option "XkbModel" "pc104"
Option "XkbLayout" "us"
EndSection
Section "InputDevice"
Identifier "Configured Mouse"
Driver "mouse"
Option "CorePointer"
Option "Device" "/dev/input/mice"
Option "Protocol" "ExplorerPS/2"
Option "ZAxisMapping" "4 5"
Option "Emulate3Buttons" "true"
EndSection
Section "InputDevice"
Driver "wacom"
Identifier "stylus"
Option "Device" "/dev/wacom" # Change to
# /dev/input/event
# for USB
Option "Type" "stylus"
Option "ForceDevice" "ISDV4" # Tablet PC ONLY
EndSection
Section "InputDevice"
Driver "wacom"
Identifier "eraser"
Option "Device" "/dev/wacom" # Change to
# /dev/input/event
# for USB
Option "Type" "eraser"
Option "ForceDevice" "ISDV4" # Tablet PC ONLY
EndSection
Section "InputDevice"
Driver "wacom"
Identifier "cursor"
Option "Device" "/dev/wacom" # Change to
# /dev/input/event
# for USB
Option "Type" "cursor"
Option "ForceDevice" "ISDV4" # Tablet PC ONLY
EndSection
Section "InputDevice"
Identifier "Serial Mouse"
Driver "mouse"
Option "Protocol" "Microsoft"
Option "Device" "/dev/ttyS0"
Option "SendCoreEvents" "true"
EndSection
Section "Device"
Identifier "Generic Video Card"
Driver "vesa"
BusID "PCI:0:8:0"
VideoRam 2048
EndSection
Section "Monitor"
Identifier "719BF"
Option "DPMS"
EndSection
Section "Screen"
Identifier "Default Screen"
Device "Generic Video Card"
Monitor "719BF"
DefaultDepth 16
SubSection "Display"
Depth 1
Modes "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 4
Modes "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 8
Modes "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 15
Modes "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 16
Modes "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 24
Modes "1024x768" "800x600"
EndSubSection
EndSection
Section "ServerLayout"
Identifier "Default Layout"
Screen "Default Screen"
InputDevice "Generic Keyboard"
InputDevice "Configured Mouse"
InputDevice "stylus" "SendCoreEvents"
InputDevice "cursor" "SendCoreEvents"
InputDevice "eraser" "SendCoreEvents"
InputDevice "Serial Mouse" "CorePointer"
EndSection
Section "DRI"
Mode 0666
EndSection
